CALB L173F314 3.2v 314ah LiFePO4 prismatic battery cell
CALB L173F314 3.2v 314ah LiFePO4 prismatic battery cell. Larger capacity, higher energy density. Brand new, A grade. Suitable for various energy storage systems such as home energy storage, industrial energy storage and container energy storage.
The CALB 314ah LiFePO4 cell and the CALB 280ah LiFePO4 cell have the same size, but the CALB 314ah cell can store more power. It has higher energy density. Therefore, many new energy storage projects use 314AH battery cell instead of 280ah battery cell, which can greatly increase the storage capacity without changing the original size.
CALB L173F314 3.2v 314ah LiFePO4 prismatic battery cell Datasheet
Battery Model: LF173F314
Nominal Voltage: 3.2v
Rated Capacity: 314Ah
Rated Energy: 1004Wh
Mass Energy Density: 179Wh/kg
Volume Energy Density: 394 Wh/L
ACR: ≤0.35 mΩ
Weight: 5.60±0.15kg
Cycle Life: ≥15000 cycles
Cell Volume: 2.55L(without terminal)
Dimension: 174.4±0.3*207±0.4*71.4±0.3mm
Positive Terminal Material: Al 1060 H14
Negative Terminal Material: Al 1060 H112 & Cu T2
Charging Temperature: 0~55°C
Discharging Temperature: -30~55°C
Storage Temperature: -30~60°C
Voltage Range: 2.5~3.65 V(0℃＜T≤55℃)
Voltage Range: 2.0~3.65 V(-30℃≤T≤0℃)
CALB L173F314 3.2v 314ah LiFePO4 prismatic battery cell Transportation
The requirements for battery transportation are as follows:
1) The battery shall be packed into boxes for transportation under 20% ~ 70% charge state;
2) During transportation, the battery shall not be subjected to severe mechanical impact, exposure to the sun and rain, and shall not be inverted;
3) In the process of loading and unloading, the battery shall be handled with care to prevent falling, rolling and heavy pressure.
CALB L173F314 3.2v 314ah LiFePO4 prismatic battery cell Storage
Battery storage requirements are as follows:
1) The storage battery shall be stored in a clean and well ventilated warehouse at a temperature of 5 ℃ ~ 35 ℃;
2) The battery shall not be exposed to direct sunlight and shall not be less than 2m away from the heat source;
3) The storage battery shall not be placed upside down or horizontally, and mechanical impact or heavy pressure shall be avoided;
4) The long-term storage shall be in 20-40% SOC state.
